Hot Melt Narrow web Coating Machine

870000 INR/Set

Get a Price/Quote

Product Details:

Type Adhesive Coating Machine, Hologram Coating Machine
Weight (kg) 330 Kilograms (kg)
Coating Speed 10 m/m
Coating Head Other
Coating Width 150 Millimeter (mm)
Computerized No
Automatic No
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Product Details
Product Description

Price And Quantity

Price 870000 INR/Set
Minimum Order Quantity 1 Set

Product Specifications

Automatic No
Computerized No
Power Consumption 6 Kilowatt (kW)
Color Blue
Weight (kg) 330 Kilograms (kg)
Dimension(L*W*H) 1.5 x1 x 1 Meter (m)
Heating System Electric
Warranty 12 months
Coating Width 150 Millimeter (mm)
Power Source Electric
Unwinding Width 150 Millimeter (mm)
Rewinding Width 150 Millimeter (mm)
Glue Type Other
Control System PLC Control
Coating Head Other
Rewinder Type Duplex Rewinder
Unwinder Type Duplex Unwinder
Coating Speed 10 m/m
Drive Type Electric
Type Adhesive Coating Machine, Hologram Coating Machine
Voltage 415 Volt (v)
Feature Low Energy Consumption, Coating

Trade Information

FOB Port Mumbai
Payment Terms Telegraphic Transfer (T/T)
Delivery Time 60 Days
Main Export Market(s) Asia, Western Europe, Middle East, Africa
Main Domestic Market All India
Certifications CE

Product Description

Machine Type: Die coating
Max. Size of coating: 150mm, GSM: 15 to 65 Max.
Speed of coating : Speed 10 mpm @30gsm
Unwind2 sets: Each set to hold 150 mm max. width material. Material of 300 mm Dia. Max., 76 MM core ID, Powder Brake 6 Nm.
Coating Station: Slot Die coating with Accurate Temp. Control. Levelling adjustments of die rolls dynamic balanced and Back up roller Pneumatically operated.
Lamination Nip: Metal roll& Silicone roll movement & pressure by Pneumatic, Clutch Drive to the nip.
Rewind: for Laminate to hold 150 mm max. width material up to 480 mm Dia. Max. 76 MM core ID. Tappertension controlled winding. Torque Drive for controlled winding.
Permelter PM 6: Tank capacity 6 Lit.. Melting Capacity 4 Lit/hr, liquid tank capacity 1 Lit., Pump Capacity 0.4 Lit/Min. , Accurate Temp. Control and Accurate flow control.
Hotmelt Hose: To Supply 0.4 Kgs/hr, Length 2 m, Accurate Temp. Control.
DIMENTIONS:1.5 m X 1 m X 1 m
Total Electrical Load: Motors 3 HP, Heaters 3.5 KW

Specifications

Coating width	100 mm Max.
No. of Rewind	2 with tension controls
No. of Unwind	2,with brakes
Winding Diameter	500 mm
Voltage	415 V
Dimensions	6 X 4 x 5
Brand	Trasy
