Double Side Hot Melt Coating Machine

Product Description

      This machine is a hot melt adhesive coating machine. The machine has two heads of slot die coating and two melting units. This enables to coat on both sides of the substrate in single            operation. As a result it gives double production and less wastage.

• Machine Type: Die coating
• Max. Size of coating: 300mm, GSM: 15 to 65 Max.
• Speed of coating : Speed 10 mpm at 30gsm
• Unwind3 sets: Each set to hold 310 mm max. width material. Material of 450 mm Dia. Max., 76 MM core ID. , Powder Brake 50Nm, Electronic Web Guide.
• Coating Station 2 Sets: Slot Die coating with Accurate Temp. Control. Levelling adjustments of die rolls dynamic balanced and Back up roller Pneumatically operated.
• Lamination Nip: Metal roll& Silicone roll movement & pressure by Pneumatic, Clutch Drive to the nip.
• Rewind: for Laminate to hold 310mm max. width material up to 480 mm Dia. Max. 76 MM core ID. Tapper tension controlled winding. AC Drive for controlled winding with magnetic Clutch of 100 Nm.
• Permelter2 sets of PM 24: Tank capacity 24 Lit.. Melting Capacity 12 Lit/hr, liquid tank capacity 12 Lit., Pump Capacity 0.4 Lit/Min. , Accurate Temp. Control and Accurate flow control.
• Hotmelt Hose 2 sets to Supply 0.4 Kgs/hr, Length 2 m, Accurate Temp. Control.
• DIMENTIONS: 3 m X 1 m X 1.5 m
• Total Electrical Load : Motors 8 HP,  Heaters10 KW
